Parkanson PKV400DM Vertical Metal Cutting Bandsaw

Parkanson PKV400DM Vertical Bandsaw

Technical Specifications

Parkanson PKV400DM Vertical Metal Cutting Bandsaw

The Parkanson PKV400DM Vertical Metal Cutting Bandsaw is a quality vertical bandsaw made in Germany.

Features:

– Infinitely variable hydraulic mitre adjustment.
– Infinitely variable hydraulic control of cutting pressure.
– Exact saw bow guidance via linear guiding shoes.
– The saw frame is specially designed to keep its position over a long period.
– Top loading of the machine is possible
– The ability to operate as a vertical saw

Specifications:

Cutting Capacity 90°: Round – 320mm; Flat 320 x 400mm
Cutting Capacity 45°: Left – 320 x 280mm; Right – 320 x 260mm
Cutting Capacity 30°: Right – 320 x 140mm
Blade Size: 3400 x 27 x 0.9mm
Blade Speed: 35/70 m/min
Main Motor: 1.4kW
Dimensions (LxWxH): 1040 x 1800 x 1900mm
Weight: 800kg
